3D Acrylic Faux Neon Signs | Premium Solid Acrylic Engraved Letter

Material & Build:15mm to 25mm solid 3D engraved acrylic face and body with a durable metal or ABS base.
Illumination Style:Acrylic neon body illumination featuring vibrant face illumination paired with side block-out styling (custom colour painted options available).
LED Color Temperatures:Available in 3,000K (Warm White), 6,500K (Natural White), and 10,000K (Cool White). Fully dynamic RGB color-changing systems and smart dimmer modules are available upon request.
Finishes & Customization:Completely customizable in size, shape, and color. The surface and body can be left clean or enhanced with polished, brushed, electroplated, powder-coated, UV-printed, or 2pac automotive-painted treatments.
Power Supply:Packed with a heavy-duty, low-voltage Meanwell Transformer (12V DC – 240V AC). All power elements carry strict local commercial certifications: SAA and C-Tick for Australia/New Zealand, UL/cUL for North America, and CE/RoHS for Europe.
Wiring & Installation:Standard 1.5m lead wire (extendable up to 3m). Each sign includes a full-scale installation template/draft for flawless setup.
All-Weather Engineering:Built with an IP-rated internal electrical core and integrated moisture drainage weep holes at the lower rear quadrant, making it suitable for interior spaces or heavy-duty outdoor exposure.
Mounting Options:Supports Flush Mount or Stand-off Mounting via M4, M6, M8, or M10 threaded pins (optional sleeves and spacers available in custom colors).

Target Applications & Use Cases

Perfect for commercial building facades, retail storefronts, corporate office lobbies, hospitality signage, interior restaurant decor, and heavy-duty outdoor architectural lighting.

Side-view-drawing

Solid Acrylic Engraved Letters with LED Illumination

Product code: 3D-002

Environment: Interior | Semi-Outdoor | Fully External (drain holes at bottom rear)
Dimensions: Refer to drawing
Face & Body: 20mm solid opal white acrylic engraved
Back: 3mm acrylic backing with illumination (5mm/10mm/20mm)
Return(Depth): 23mm (20+3)
Finish: Face + rear side illumination, side block out (colour painted TBC)
LED Options: LED modules 3,000K (Warm White) | 6,500K (Natural White) | 10,000K (Cool White)
Coloured acrylic, RGB LEDs and Dimmers available at extra cost.
Illumination Style: Dual-direction (Face and Rear/Halo illumination) with light-blocking painted sides (Colour TBC).
Wiring: Standard 1.5m lead (Maximum extension up to 3m).
Installation Guide: Full-scale installation template/draft included
Installation Method: Flush Mount or Stand-off Mounting
-M4 / M6 / M8 / M10 threaded pins (Optional sleeves/nuts/spacers available in custom colours).
Power Supply: 12V DC – 240V AC C-Tick certified Meanwell Transformer.

Yes. This signage style is explicitly engineered for multiple environments, including interior, semi-outdoor, and fully external applications. For fully external installations, the letters are manufactured with integrated drain holes at the bottom rear to ensure proper water drainage and weather resistance.

This product features an Acrylic Neon Body Illuminate style, offering bright face illumination. It is paired with a side block-out design (where the side returns are painted to block light) to focus the illumination forward, creating a sharp, high-contrast, 3D neon tube effect inside a structural letter canal.

The face and body are constructed from a heavy-duty 15mm to 25mm solid acrylic 3D engrave, which houses the curved LED neon elements. The return depth is fully customized to the demanded size of your project. The backing of the letters features a sturdy Metal or ABS base for secure installation.

Every sign package is built with a 1.5-metre lead wire (extendable to a maximum of 3 metres) connected to a heavy-duty, low-voltage 12V DC – 240V AC Meanwell Transformer. To guarantee passing local building inspections and electrical compliance, our systems feature regional certification networks: SAA and C-Tick for Australia/New Zealand, UL/cUL for North America, and CE/RoHS for Europe. This low-voltage setup keeps the thick structural acrylic cool to the touch and highly energy-efficient compared to traditional glass neon.

The letters support both Flush Mount and Stand-off Mounting methods. To ensure a simple, mistake-free installation, a full-scale paper layout template/draft is provided with the custom set. For standard structural flush fixed setups, the signage kit comes packed with heavy-duty M4*50mm screws to firmly anchor the letters to the flat backing substrate.

To deliver a precise, guaranteed custom proposal within 12 working hours, please provide our engineering team with:

Your vector branding layout file (.AI, .EPS, or editable .PDF format) outlining the typography or logo with your required overall width and height marked.
Your choice of metal material and surface finish for the side returns (e.g., Brushed Gold, Mirror Silver, or a specific Pantone powder-coated paint color).
The preferred illumination profile (static color temperature or dynamic RGB color-changing functionality).
The exact installation context (Fully Interior, Shopping Center, or Semi-Outdoor) along with your location details to ensure regional safety compliance matching.
